Evidence Recorder version 9.0.0 Downloads Page
A New Licensing System
If you are upgrading from an older version of Evidence Recorder then a new license key is required.
We have an entirely new software licensing system. Please click here to go to our Licensing Instructions page and learn how to license your new version.
Step 1: Install Microsoft ActiveSync or Windows Mobile Device Center
In order to install Evidence Recorder onto your hand-held data collector, you must have Microsoft ActiveSync (for Windows XP or earlier) or Microsoft Windows Mobile Device Center (for Windows Vista and 7) installed on your computer. Click here to download these free from Microsoft
Step 2: Install Evidence Recorder
Evidence Recorder 9.0.0 uses an installer where all devices are available in the same install package. Download the install package below to your computer and run the setup. The install will attempt to connect to your device through Activesync or Windows Mobile Device Center and install the software.
Download Devices Installer for Evidence Recorder 9.0.0
Step 3: Install MicroSurvey Transfer
The MicroSurvey Transfer program provides an easy means of transferring Evidence Recorder project files between your data collector and your desktop computer. Install this latest version if your MapScenes Forensic CAD software has been recently updated.
Step 4 (Optional): Install Datum Grid Editor
Only GPS users may require this program. If you are recording data with a non-GPS instrument such as a total station or robotic total station then you do not need a geoid model and moreover, you don't need the Datum Grid Editor. This is a desktop (runs on a PC, not a data collector) program is used to create a subset of a geoid model file.
What is a geoid model?
A geoid model is a file that is used to convert ellipsoidal heights (what GPS measures) into heights based off of "mean sea level" (also called orthometric heights). Orthometric heights are more meaningful to land surveyors than ellipsoidal heights. It is a lot more difficult to find where the ellipsoid is on the earth versus where mean sea level is. After you load the geoid model file onto your data collector, Evidence Recorder will use it to convert GPS-measured ellipsoidal heights to orthometric heights.
Why do I need to install and use the Datum Grid Editor?
Older Data Collectors
In the past, data collectors came with a smaller memory-storage capacity. Geoid model files could easily fill up the entire data collector's hard drive or were even too large to transfer to the device at all.
Because of this we created this utility that makes a subset of the geoid model that is small enough to fit onto a data collector's hard drive. Typically you would create a subset based on the location of the project area. Currently, all MicroSurvey data collectors come with an enormous storage-memory capacity therefore making geoid model subsets unnecessary (now we just copy the entire geoid model file onto the data collector), and that is one of the reasons why we say it is "optional".
If you wish to create a geoid model subset, click on the link below to download the Datum Grid Editor.
Note: The Datum Grid Editor currently only works on North American geoid models.
This subset must then be copied onto your data collector in the following directory, overwriting some of the existing files that are already there:
...\MicroSurvey EVR9\Programs\Mapping
Remember: If you are not collecting data using GPS then you do not need to use a geoid model, and therefore do not need to use Datum Grid Editor. (Another reason why we say it is "optional".)
Movie: Instructions for Datum Grid Editor use
Step 5 (Optional): Desktop Version
You can install a desktop version of Evidence Recorder to use for training or testing. The desktop version is now Windows Vista and 7 compatible. There is no need to run Evidence Recorder as an administrator. This installation will be needed to use Evidence Recorder on tablet computers such as the Algiz.
Download Desktop Installer for Evidence Recorder 9.0.0
Evidence Recorder Release Notes and Manual
Remember: to save these files to your hard drive, right-click on the link and select either "save link as" or "save target as".
Click here to download the Evidence Recorder 9.0.0 Manual
Click here to download the Evidence Recorder Release Notes.
Older Installs
Looking for all the Evidence Recorder installs? Click here to access previous versions of EVR.
